1 1/2" BANJO Y-STRAINER 80 MESH POLYPRO 8 GPM PRESSURE WASHER
Banjo Polypropylene Y-Strainer 1 1/2" 316 Stainless Steel 80 mesh EPDM seal 150 PSI maximum.
11.5" x 8"
Water filter for 8 GPM and greater pressure washers. This filter is included in the PL-8-to and PL-8-TA kits.
Please do NOT forget to add the 1.5" Hose Barbs and the special 3/4" to 1.5" Hose Barb to help you properly plumb this filter. We created a plumbing diagram located at pressurewasherproducts.com to assist you with plumbing.
***Supply/Suction hose inner diameter (ID) should be doubled compared to the pump Inlet/Suction port. For example, the General Pump TSF2021 has 3/4" Inlets on located on either side of the bottom manifold of the pump. The pump should be supplied with a 1 1/2" non-collapsible suction hose (AGC24).
Have you ever wondered how to plumb your power washer correctly?
Pressure washer products love to share knowledge. Mount the pressure washer as low to the surface as possible in relation to the supply Port/Bulkhead of the water tank but remember to use Shock shock-absorbing rubber Pucks (Part# 4542) on your skid l-Brackets (1215) of the pressure washer. Most pressure washers can be converted from carts with wheels to skid units by removing the wheels and installing l-Brackets for your unit available through us.
Minimize the use of extra fittings do NOT use Galvanized fittings or Metal Ball valves between your pump and water tank because they will likely corrode and flake little chunks into your pump valves leading to vibration and/or damage. Avoid extra elbows do NOT use PVC Pipe anywhere. PVC Pipe can become brittle and doesn't tolerate the weight of a surface cleaner, ladder, or your body weight for long. If is NOT installed correctly air will find its way into your pump leading to manifold damage. Install components using non-drying liquid Teflon and never use Teflon tape, never adjust your unloader. The unloader should be set using a Whip Hose, high-pressure ball valve, high-pressure steel tee, snubber, and gauge to 200 psi above the operating pressure of the pump and left alone. Do not install check valves or any swivel fitting on the Suction/Supply Hose assembly or air may become entrained causing extensive damage from cavitation.
Working with a non-collapsible hose can be challenging. We have several Heat Guns and Ratcheting PVC Hose cutters to tame the hose. When installing the hose into hose barbs, first slide the hose clamp a few feet away from the cut end. Grab some Slo-Mo Soft wash surfactant for Sodium Hypochlorite, dish soap, or shampoo, and coat your finger or old toothbrush with a generous amount. Apply the soap to the inside several inches and to the barb end of the Hose Barb. Turn on the Heat Gun and hold the heat source about 3-4" away from the hose end while rotating the hose as you try to apply the heat as evenly as possible. Heat only until the hose turns shiny and releases a single plume of smoke. Please turn off the Heat Gun and set it aside to cool. Install the barb into the hose end and push it down against the ground or vertical surface. Allow the end to cool naturally, move the hose clamp up about 1/16" or 1/8" from the end toward the thread, and tighten securely.
Install the hose clamp to allow you to access it easily in the future so that you do not have to struggle to use a tool on the clamp.
The Unloader Bypass hose that sends water back to the tank when you release the trigger on your gun should be installed using a 3/8" or 1/2" Kink resistant hose or yellow AG hose. The port should be installed so that the stream of water shooting into the tank does not point directly at the pressure washer suction/supply Bulkhead. You do NOT want to create air bubbles in your supply water. The Bypass hose running back to your tank will act as a backup for your thermal relief valve mounted on the opposite side of your pump to the suction hose assembly.
A few words about the high-pressure side of the pump:
Do not use Teflon tape on any fittings. Use medium, removable thread lock (5003, 10ML or 5004 50ML). Try not to use elbows or extra fittings. When at all possible, minimize the use of quick connects. Install the chemical injector at least 3" away from the unloader to prevent back-siphoning of chemicals into the internal components of the unloader. Always remove the chemical injector assembly when not in use. You can install a chemical injector Bypass kit.
Use an R2 or two (2) Wire Jump hose on the high-pressure outlet of your unloader to your reel.
Before purchasing a telescoping wand try out some long-range nozzles such as 0020, 0025, 0030, 0035, 0040, 0050, and 0060 installed into female plugs. To improve your vertical reach with these nozzles, use them with a 6", 7", 8", 10", or 12" Aluminum Wand and a side handle (1536) for added control. Choose from one of our 6540-8 JROD kits selected for your flow and pressure.
When using 8 GPM or more, use a 1/2" ID High-Pressure Jump hose to your reel, use 50" of 1/2" ID High-Pressure hose coming off the reel, and replace the 1/4" ID High-Pressure hose on your surface cleaner with 3/8" ID. We can custom cut and cramp your High-Pressure hose to your desired length and ship it to you.
