8.5 gpm 4200 psi Skid Cold Pressure Washer Honda Engine AR XW30.28N
8.5 gpm 4000 psi Skid Cold Pressure Washer Honda Engine Annovi Reverberi XW30.28N
Pressure Washer Only
8.5 gpm 4200 psi Honda GX690 24 HP Annovi Reverberi XW30.28N Belt drive , powder coated steel frame and 1/2" blue spring high volume pressure trapped unloader
This unit is IN STOCK.
Standard features
- Lifetime frame warranty on powder coated steel frame
- 3/8" Coupler installed on the outlet of 1/2" unloader (Reduced at outlet)
- 1/2" Brass barb installed on the bypass outlet (Need bypass hose AGY08)
- High flow 1/2" ported VRT100 unloader
- 4 x 3VX Belts
- Engine and pump oil drains
- 29" L x 29" W x 20" H
- 185 Lbs
- Mounted on anti-vibration pads or hockey pucks
- Starter side exhaust
- Must add 2 or 4 AWG battery cables and battery/box
- Honda GX690 Key Start Engine w/ Honda 3 Year warranty
- Annovi Reverberi standard pump warranty
- Oil prefilled in pump and engine
- 30W Non-Detergent oil for pump (1.3 qts on average change)
- 10W30 oil for engine
We highly recommend adding:
The best high pressure 3/8" ball valve (6292.SM) to this order to allow you to turn off the high pressure flow of water to switch from the gun to a Whisper Wash Classic surface cleaner (4345W). You need 4 x 2.5 orifice 25 degree nozzles for a four tip bar (2812) or 2 x 4.5 orifice 25 degree nozzles for a two tip bar (1122).
This unit will need 8.5 or 9.0 nozzles and a 5 - 8 gpm 2.3 mm chemical injector assembly.
We carry everything you need to plumb this pressure washer in a kit which is part number, PL-8-TA for a horizontal leg tank or PL-8-TO for an IBC tote. If buying the kit, you will need the 1/2" bypass barb. You will need to add 10-15' of AGY08. The kits do include the bypass hose.
Choose a 9.0 turbo nozzle for this pressure washer.
Do not adjust your unloader!
The unloader is set at a spike pressure of 200 psi above the operating pressure of the pump and meant to be left alone. If you need less pressure, change out the nozzles to a larger orifice and never smaller than what is called for using factory specifications using gpm and pressure. This unit requires a 8.5 orifice or larger. You can add a 6540-8 JROD kit to play with nozzle distances and pressures.
Install a high temperature Hudson float valve (Hudson-HT) using everything you need to install it into your water tank with our Hudson Installation Kit (HB). The Hudson installation kit installs into the very top of the tank using a bulkhead and barb to prevent the tank from over-flowing.
- Add a fuel tank
- Try a Lori Lift Kit and make your life easier! Lift your unit up.
- Need a gun, click here?
- Hose?
